逐步详解 SHA-2 算法(以 SHA-256 为例)

最常见的 SHA-2 算法是如何实现的?本文逐步为你讲解。

SHA-2 (Secure Hash Algorithm 2),是最流行的哈希算法之一,包括了:SHA-224SHA-256SHA-384SHA-512SHA-512/224SHA-512/256。这些变体除了生成摘要的长度、循环运行的次数等一些细微差异之外,基本结构是一致的。

SHA-2 以安全和速度著称,在未生成密钥的情况下(例如挖掘比特币),像 SHA-2 这样的快速哈希算法通常占据上风。

哈希函数(Hash Function)

如果,你还不清楚哈希是什么,可以参见我的另外一篇文章

简单来说,哈希函数的拥有如下三个重要特性:

  • 哈希函数对数据进行确定性加扰。

  • 无论输入是什么,哈希函数的输出始终具有相同的长度(大小)。

  • 无法从加扰数据中检索原始数据(单向函数)。

SHA-2 vs SHA-256

有人可能会困惑:欸?我平时看到的都是 SHA-128SHA-256 等等,这个 SHA-2 又是什么?

SHA-2 是一种算法,一种关于如何哈希数据的广义思想。SHA-256 设置了定义 SHA-2 算法行为的附加常量。其中一个常量是输出大小,“256” 和 “512” 是指它们各自的输出摘要大小(以位为单位)。

逐步详解 SHA-256

接下来举例说明 SHA-256 如何工作:

第一步:消息预处理

  1. hello world 转换为二进制

    01101000 01100101 01101100 01101100 01101111 00100000 01110111 01101111 01110010 01101100 01100100

  2. 尾部追加单独的 1

    01101000 01100101 01101100 01101100 01101111 00100000 01110111 01101111 01110010 01101100 01100100 1

  3. 填充 0 直到数据为 512 的整数倍,再减去 64 位(在本例中剩下 448 位):

    01101000 01100101 01101100 01101100 01101111 00100000 01110111 01101111

    01110010 01101100 01100100 10000000 00000000 00000000 00000000 00000000

    00000000 00000000 00000000 00000000 00000000 00000000 00000000 00000000

    00000000 00000000 00000000 00000000 00000000 00000000 00000000 00000000

    00000000 00000000 00000000 00000000 00000000 00000000 00000000 00000000

    00000000 00000000 00000000 00000000 00000000 00000000 00000000 00000000

    00000000 00000000 00000000 00000000 00000000 00000000 00000000 00000000

  4. 在末尾附加新的 64 位,这 64 位是一个大端整数,用于表示原始二进制输入的长度。在本文的例子中,是 88,或者二进制,1011000

    01101000 01100101 01101100 01101100 01101111 00100000 01110111 01101111

    01110010 01101100 01100100 10000000 00000000 00000000 00000000 00000000

    00000000 00000000 00000000 00000000 00000000 00000000 00000000 00000000

    00000000 00000000 00000000 00000000 00000000 00000000 00000000 00000000

    00000000 00000000 00000000 00000000 00000000 00000000 00000000 00000000

    00000000 00000000 00000000 00000000 00000000 00000000 00000000 00000000

    00000000 00000000 00000000 00000000 00000000 00000000 00000000 00000000

    00000000 00000000 00000000 00000000 00000000 00000000 00000000 01011000

现在,得到了初始的输入值(通过对消息进行补位处理,最终的长度应该是 512 位的倍数)。

第二步:初始化哈希值(h)

现在,初始化 8 个哈希值。这些是硬编码的常数,分别代表前 8 个素数(2、3、5、7、11、13、17、19)的平方根的小数部分的前 32 位:

h0 := 0x6a09e667

h1 := 0xbb67ae85

h2 := 0x3c6ef372

h3 := 0xa54ff53a

h4 := 0x510e527f

h5 := 0x9b05688c

h6 := 0x1f83d9ab

h7 := 0x5be0cd19

第三步:初始化圆常数(k)

与步骤 2 类似,初始化一些常量,一共有 64 个。每个值(0-63)是前 64 个素数(2-311)的立方根分数部分的前 32 位。

0x428a2f98 0x71374491 0xb5c0fbcf 0xe9b5dba5 0x3956c25b 0x59f111f1

0x923f82a4 0xab1c5ed5 0xd807aa98 0x12835b01 0x243185be 0x550c7dc3

0x72be5d74 0x80deb1fe 0x9bdc06a7 0xc19bf174 0xe49b69c1 0xefbe4786

0x0fc19dc6 0x240ca1cc 0x2de92c6f 0x4a7484aa 0x5cb0a9dc 0x76f988da

0x983e5152 0xa831c66d 0xb00327c8 0xbf597fc7 0xc6e00bf3 0xd5a79147

0x06ca6351 0x14292967 0x27b70a85 0x2e1b2138 0x4d2c6dfc 0x53380d13

0x650a7354 0x766a0abb 0x81c2c92e 0x92722c85 0xa2bfe8a1 0xa81a664b

0xc24b8b70 0xc76c51a3 0xd192e819 0xd6990624 0xf40e3585 0x106aa070

0x19a4c116 0x1e376c08 0x2748774c 0x34b0bcb5 0x391c0cb3 0x4ed8aa4a

0x5b9cca4f 0x682e6ff3 0x748f82ee 0x78a5636f 0x84c87814 0x8cc70208

0x90befffa 0xa4506ceb 0xbef9a3f7 0xc67178f2

第四步:块循环

对输入的每 512 位分为一块,执行以下步骤:

注意
在本文的例子中,因为 “hello world” 太短了,所以只有一个块。在循环的每一次迭代中,都将对哈希值 h0-h7 进行变更,最终作为结果输出。

第五步:重组信息数组(w)

  1. 将步骤 1 中的输入数据重新排列到新数组中,其中每个条目都是一个 32 位字:

    01101000011001010110110001101100 01101111001000000111011101101111

    01110010011011000110010010000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000001011000

  2. 再加上 48 个初始化为零的字,这样就有了一个数组 w [0…63]

    01101000011001010110110001101100 01101111001000000111011101101111

    01110010011011000110010010000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000001011000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    … …

    00000000000000000000000000000000 00000000000000000000000000000000

  3. 使用以下算法修改数组末尾的零索引:

    1
    2
    3
    4
    5
    6

    For i from w[16…63]:
        s0 = (w[i-15] rightrotate 7) xor (w[i-15] rightrotate 18) xor (w[i-15] rightshift 3)

        s1 = (w[i- 2] rightrotate 17) xor (w[i- 2] rightrotate 19) xor (w[i- 2] rightshift 10)

        w[i] = w[i-16] + s0 + w[i-7] + s1


    以 w[16] 举例说明:

    w[1] rightrotate 7:

    01101111001000000111011101101111 -> 11011110110111100100000011101110

    w[1] rightrotate 18:

    01101111001000000111011101101111 -> 00011101110110111101101111001000

    w[1] rightshift 3:

    01101111001000000111011101101111 -> 00001101111001000000111011101101

    s0 = 11011110110111100100000011101110

    XOR 00011101110110111101101111001000

    XOR 00001101111001000000111011101101

    = 11001110111000011001010111001011

    w[14] rightrotate 17:

    00000000000000000000000000000000 -> 00000000000000000000000000000000

    w[14] rightrotate19:

    00000000000000000000000000000000 -> 00000000000000000000000000000000

    w[14] rightshift 10:

    00000000000000000000000000000000 -> 00000000000000000000000000000000

    s1 = 00000000000000000000000000000000

    XOR 00000000000000000000000000000000

    XOR 00000000000000000000000000000000

    = 00000000000000000000000000000000

    w[16] = w[0] + s0 + w[9] + s1

    = 01101000011001010110110001101100

    • 11001110111000011001010111001011
    • 00000000000000000000000000000000
    • 00000000000000000000000000000000
      = 00110111010001110000001000110111

    // addition is calculated modulo $ 2^{32} $

    总的结果就是:

    01101000011001010110110001101100 01101111001000000111011101101111

    01110010011011000110010010000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000000000000

    00000000000000000000000000000000 00000000000000000000000001011000

    00110111010001110000001000110111 10000110110100001100000000110001

    11010011101111010001000100001011 01111000001111110100011110000010

    00101010100100000111110011101101 01001011001011110111110011001001

    00110001111000011001010001011101 10001001001101100100100101100100

    01111111011110100000011011011010 11000001011110011010100100111010

    10111011111010001111011001010101 00001100000110101110001111100110

    10110000111111100000110101111101 01011111011011100101010110010011

    00000000100010011001101101010010 00000111111100011100101010010100

    00111011010111111110010111010110 01101000011001010110001011100110

    11001000010011100000101010011110 00000110101011111001101100100101

    10010010111011110110010011010111 01100011111110010101111001011010

    11100011000101100110011111010111 10000100001110111101111000010110

    11101110111011001010100001011011 10100000010011111111001000100001

    11111001000110001010110110111000 00010100101010001001001000011001

    00010000100001000101001100011101 01100000100100111110000011001101

    10000011000000110101111111101001 11010101101011100111100100111000

    00111001001111110000010110101101 11111011010010110001101111101111

    11101011011101011111111100101001 01101010001101101001010100110100

    00100010111111001001110011011000 10101001011101000000110100101011

    01100000110011110011100010000101 11000100101011001001100000111010

    00010001010000101111110110101101 10110000101100000001110111011001

    10011000111100001100001101101111 01110010000101111011100000011110

    10100010110101000110011110011010 00000001000011111001100101111011

    11111100000101110100111100001010 11000010110000101110101100010110

第六步:压缩

  1. 初始化变量 a,b,c,d,e,f,g,h,并将它们分别设置为等于当前的哈希值:h0,h1,h2,h3,h4,h5,h6,h7

  2. 进行压缩循环。 压缩循环将改变 a…h 的值。压缩循环如下:

     1
     2
     3
     4
     5
     6
     7
     8
     9
    10
    11
    12
    13
    14

    for i from 0 to 63:
        S1 = (e rightrotate 6) xor (e rightrotate 11) xor (e rightrotate 25)
        ch = (e and f) xor ((not e) and g)
        temp1 = h + S1 + ch + k[i] + w[i]
        S0 = (a rightrotate 2) xor (a rightrotate 13) xor (a rightrotate 22)
        maj = (a and b) xor (a and c) xor (b and c)
        temp2 := S0 + maj
        h = g
        g = f
        e = d + temp1
        d = c
        c = b
        b = a
        a = temp1 + temp2


    下面演示第一次迭代,所有加法都是以 $ 2^{32} $ 为模的:

    a = 0x6a09e667 = 01101010000010011110011001100111

    b = 0xbb67ae85 = 10111011011001111010111010000101

    c = 0x3c6ef372 = 00111100011011101111001101110010

    d = 0xa54ff53a = 10100101010011111111010100111010

    e = 0x510e527f = 01010001000011100101001001111111

    f = 0x9b05688c = 10011011000001010110100010001100

    g = 0x1f83d9ab = 00011111100000111101100110101011

    h = 0x5be0cd19 = 01011011111000001100110100011001

    e rightrotate 6:

    01010001000011100101001001111111 -> 11111101010001000011100101001001

    e rightrotate 11:

    01010001000011100101001001111111 -> 01001111111010100010000111001010

    e rightrotate 25:

    01010001000011100101001001111111 -> 10000111001010010011111110101000

    S1 = 11111101010001000011100101001001

    XOR 01001111111010100010000111001010

    XOR 10000111001010010011111110101000

    = 00110101100001110010011100101011

    e and f:

    01010001000011100101001001111111 & 10011011000001010110100010001100 = 00010001000001000100000000001100

    not e:

    01010001000011100101001001111111 -> 10101110111100011010110110000000

    (not e) and g:

    10101110111100011010110110000000 & 00011111100000111101100110101011 = 00001110100000011000100110000000

    ch = (e and f) xor ((not e) and g)

    = 00010001000001000100000000001100

    XOR 00001110100000011000100110000000

    = 00011111100001011100100110001100

    // k[i] 是圆常数

    // w[i] 信息数组

    temp1 = h + S1 + ch + k[i] + w[i]

    = 01011011111000001100110100011001 + 00110101100001110010011100101011 + 00011111100001011100100110001100 + 1000010100010100010111110011000 + 01101000011001010110110001101100 = 01011011110111010101100111010100

    a rightrotate 2:

    01101010000010011110011001100111 -> 11011010100000100111100110011001

    a rightrotate 13:

    01101010000010011110011001100111 -> 00110011001110110101000001001111

    a rightrotate 22:

    01101010000010011110011001100111 -> 00100111100110011001110110101000

    S0 = 11011010100000100111100110011001

    XOR 00110011001110110101000001001111

    XOR 00100111100110011001110110101000

    = 11001110001000001011010001111110

    a and b:

    01101010000010011110011001100111 & 10111011011001111010111010000101 = 00101010000000011010011000000101

    a and c:

    01101010000010011110011001100111 & 00111100011011101111001101110010 = 00101000000010001110001001100010

    b and c:

    10111011011001111010111010000101 & 00111100011011101111001101110010 = 00111000011001101010001000000000

    maj = (a and b) xor (a and c) xor (b and c)

    = 00101010000000011010011000000101

    XOR 00101000000010001110001001100010

    XOR 00111000011001101010001000000000

    = 00111010011011111110011001100111

    temp2 = S0 + maj = 11001110001000001011010001111110 + 00111010011011111110011001100111 = 00001000100100001001101011100101

    h = 00011111100000111101100110101011

    g = 10011011000001010110100010001100

    f = 01010001000011100101001001111111

    e = 10100101010011111111010100111010 + 01011011110111010101100111010100 = 00000001001011010100111100001110

    d = 00111100011011101111001101110010

    c = 10111011011001111010111010000101

    b = 01101010000010011110011001100111

    a = 01011011110111010101100111010100 + 00001000100100001001101011100101 = 01100100011011011111010010111001

    整个计算会继续循环进行了 63 次,期间不断修改了变量 a-h 的值。最终结果为:

    a = 4F434152 = 001001111010000110100000101010010

    b = D7E58F83 = 011010111111001011000111110000011

    c = 68BF5F65 = 001101000101111110101111101100101

    d = 352DB6C0 = 000110101001011011011011011000000

    e = 73769D64 = 001110011011101101001110101100100

    f = DF4E1862 = 011011111010011100001100001100010

    g = 71051E01 = 001110001000001010001111000000001

    h = 870F00D0 = 010000111000011110000000011010000

第七步:修改最终值

压缩循环完成后,仍然处于在块循环中,通过向哈希值中添加它们各自的变量 a-h 来修改哈希值。同样的,所有的加法都是模 $ 2^{32} $。

h0 = h0 + a = 10111001010011010010011110111001

h1 = h1 + b = 10010011010011010011111000001000

h2 = h2 + c = 10100101001011100101001011010111

h3 = h3 + d = 11011010011111011010101111111010

h4 = h4 + e = 11000100100001001110111111100011

h5 = h5 + f = 01111010010100111000000011101110

h6 = h6 + g = 10010000100010001111011110101100

h7 = h7 + h = 11100010111011111100110111101001

第八步: 组成最终的哈希值

1
2
digest = h0 append h1 append h2 append h3 append h4 append h5 append h6 append h7
       = B94D27B9934D3E08A52E52D7DA7DABFAC484EFE37A5380EE9088F7ACE2EFCDE9

搞定!至此,本文非常详细地实现了 SHA-256 中的每一步 🙂。

附录

https://cdn.jsdelivr.net/gh/techkoala/techkoala.github.io@master/images/Algorithm/SHA-2/SHA-2.png
SHA-2 的第 t 个加密循环

下面这段伪代码总结了上面执行的所有步骤:

几点说明
  1. 所有变量均为 32 位无符号整数,加法以 $ 2^{32} $ 为模

  2. 对于每一轮,在消息调度数组 w [i],0≤i≤63 中有一个循环常数 k [i] 和一个条目。

  3. 压缩函数使用 8 个工作变量,a 到 h。

  4. 在此伪代码中表示常量时使用大端约定,并且当将消息块数据从字节解析到字时,例如,填充后的输入消息 “abc” 的第一个字是 0x61626380

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
Initialize hash values:
(first 32 bits of the fractional parts of the square roots of the first 8 primes 2..19):
h0 := 0x6a09e667
h1 := 0xbb67ae85
h2 := 0x3c6ef372
h3 := 0xa54ff53a
h4 := 0x510e527f
h5 := 0x9b05688c
h6 := 0x1f83d9ab
h7 := 0x5be0cd19

Initialize array of round constants:
(first 32 bits of the fractional parts of the cube roots of the first 64 primes 2..311):
k[0..63] :=
   0x428a2f98, 0x71374491, 0xb5c0fbcf, 0xe9b5dba5, 0x3956c25b, 0x59f111f1, 0x923f82a4, 0xab1c5ed5,
   0xd807aa98, 0x12835b01, 0x243185be, 0x550c7dc3, 0x72be5d74, 0x80deb1fe, 0x9bdc06a7, 0xc19bf174,
   0xe49b69c1, 0xefbe4786, 0x0fc19dc6, 0x240ca1cc, 0x2de92c6f, 0x4a7484aa, 0x5cb0a9dc, 0x76f988da,
   0x983e5152, 0xa831c66d, 0xb00327c8, 0xbf597fc7, 0xc6e00bf3, 0xd5a79147, 0x06ca6351, 0x14292967,
   0x27b70a85, 0x2e1b2138, 0x4d2c6dfc, 0x53380d13, 0x650a7354, 0x766a0abb, 0x81c2c92e, 0x92722c85,
   0xa2bfe8a1, 0xa81a664b, 0xc24b8b70, 0xc76c51a3, 0xd192e819, 0xd6990624, 0xf40e3585, 0x106aa070,
   0x19a4c116, 0x1e376c08, 0x2748774c, 0x34b0bcb5, 0x391c0cb3, 0x4ed8aa4a, 0x5b9cca4f, 0x682e6ff3,
   0x748f82ee, 0x78a5636f, 0x84c87814, 0x8cc70208, 0x90befffa, 0xa4506ceb, 0xbef9a3f7, 0xc67178f2

Pre-processing (Padding):
begin with the original message of length L bits
append a single '1' bit
append K '0' bits, where K is the minimum number >= 0 such that L + 1 + K + 64 is a multiple of 512
append L as a 64-bit big-endian integer, making the total post-processed length a multiple of 512 bits

Process the message in successive 512-bit chunks:
break message into 512-bit chunks
for each chunk
    create a 64-entry message schedule array w[0..63] of 32-bit words
    (The initial values in w[0..63] don't matter, so many implementations zero them here)
    copy chunk into first 16 words w[0..15] of the message schedule array

    Extend the first 16 words into the remaining 48 words w[16..63] of the message schedule array:
    for i from 16 to 63
        s0 := (w[i-15] rightrotate  7) xor (w[i-15] rightrotate 18) xor (w[i-15] rightshift  3)
        s1 := (w[i- 2] rightrotate 17) xor (w[i- 2] rightrotate 19) xor (w[i- 2] rightshift 10)
        w[i] := w[i-16] + s0 + w[i-7] + s1

    Initialize working variables to current hash value:
    a := h0
    b := h1
    c := h2
    d := h3
    e := h4
    f := h5
    g := h6
    h := h7

    Compression function main loop:
    for i from 0 to 63
        S1 := (e rightrotate 6) xor (e rightrotate 11) xor (e rightrotate 25)
        ch := (e and f) xor ((not e) and g)
        temp1 := h + S1 + ch + k[i] + w[i]
        S0 := (a rightrotate 2) xor (a rightrotate 13) xor (a rightrotate 22)
        maj := (a and b) xor (a and c) xor (b and c)
        temp2 := S0 + maj

        h := g
        g := f
        f := e
        e := d + temp1
        d := c
        c := b
        b := a
        a := temp1 + temp2

    Add the compressed chunk to the current hash value:
    h0 := h0 + a
    h1 := h1 + b
    h2 := h2 + c
    h3 := h3 + d
    h4 := h4 + e
    h5 := h5 + f
    h6 := h6 + g
    h7 := h7 + h

Produce the final hash value (big-endian):
digest := hash := h0 append h1 append h2 append h3 append h4 append h5 append h6 append h7

参考
